Jazan 16

17 meter

Steel

,

Product ID

LOYD 241

Hull Material

Steel

Vessel Name

Jazan 16

Dimensions

Length O.A.

17 m

Beam O.A.

7.7 m

Depth at Sides

3.1 m

Draft

2.25 m

Capacity

Fuel Oil Capacity

16 m³

Fresh Water Capacity

5 m³

Sewage Capacity

1.6 m³

General Arangement

It is the general arangement of previously produced boats, it can be changed according to your wishes.

Standart

Standart Main propulsion comprises a pair of Caterpillar C32 Diesel engines each rated 2 x 1000hp at 1800 rpm, and each driving fixed pitched 0.86 m diameter propellers on conventional shaft lines.

Optional
