28M CREW BOAT

9,90M MOORING BOAT - LINE HANDLER LOYD OFFERS DIFFERENT TYPE OF MILITARY VESSELS ; PATROL BOAT , RESCUE BOAT, ANTI PIRACY BOAT , RIB , LANDING CRAFT . STANDARD DIMENSIONS FOR MILITARY BOATS; FROM LOA:7 METERS TO LOA:24 METERS. OUR STANDARD EQUIPMENTS; AS MAIN ENGINES MAN , CUMMINS , DOOSAN , CATERPILLAR , YANMAR , IVECO , SCANIA , VOLVO , BAUDOUIN , MITSUBISHI , MERCURY. AS GEAR BOX ; ZF , DONGI , TWINDISC .

28M CREW BOAT

Boat
overview

Loyd offers different type of military vessels ; Patrol boat , Rescue boat, Anti piracy boat , Rib , Landing Craft . Standard dimensions for military boats; from Loa:7 meters to Loa:24 meters. Our standard equipments; As main engines MAN , Cummins , Doosan , Caterpillar , Yanmar , Iveco , Scania , Volvo , Baudouin , Mitsubishi , Mercury. As gear box ; ZF , Dongi , Twindisc .

As propulsion system ; Conventional fixed pitch propeller , Water jet , stern drive , Out board. As auxiliary engine ; Cummins , Perkins . Deck Layout : Anchor , Chain , Anchor windlass , requested military equipment . Nautical & communication equipments ; Search light , Radar , Gps , Echo sounder , Vhf .

Loydshipyard uses Steel ( DH 36 ) , Aluminium ( 5083 H321 ) & HDPE ( High density polyethylene ) materials for Hull and superstructure constructions .Our military boats can be cover with bulletproof materials to keep safety at high level . Loyd shipyard manufactures military boats according to IACS member class rules. Our military boats speed range ; from 12 knots to 60 knots.

Our experienced team remain at your disposal , please do not hesitate to contact us 7/24.

Type of workboat

Crew Boat

Hull Material

Steel

Speed

14 Knots

Power

Boat
highlights

9,90M MOORING BOAT - LINE HANDLER LOYD OFFERS DIFFERENT TYPE OF MILITARY VESSELS ; PATROL BOAT , RESCUE BOAT, ANTI PIRACY BOAT , RIB , LANDING CRAFT . STANDARD DIMENSIONS FOR MILITARY BOATS; FROM LOA:7 METERS TO LOA:24 METERS. OUR STANDARD EQUIPMENTS; AS MAIN ENGINES MAN , CUMMINS , DOOSAN , CATERPILLAR , YANMAR , IVECO , SCANIA , VOLVO , BAUDOUIN , MITSUBISHI , MERCURY. AS GEAR BOX ; ZF , DONGI , TWINDISC .
Basic Information CLASSIFICATION
28M CREW BOAT
Length OA 27.60 m
Beam OA 7,58 m
Depth at sides 3,57 m
Draught Aft 2,50 m
Displacement 95 tons
Speed 14 knots
C193
28M CREW BOAT
DIMENSIONS
Length OA  27.60 m
Beam OA  7.58 m
Depth at sides  3.57 m
Draught Aft  2.50 m
Displacement  95 tons
TANK CAPACITIES
Fuel-Oil  22.4 m3
Fresh Water  6.14 m3
Bilge Water  2.00 m3
Grey Water  3.00 m3
PERFORMANCES
Speed  14 knots
PROPULSION SYSTEM
Main Engines  2x BAUDIN
Total Power  2x 1400hp @ 1950rpm
Gear Boxes  2x ZF 3055A
Propulsion  2x Fixed Pitch Propellers
Bowthruster  Optional
AUXILIARY EQUIPMENT
Main Generator  45 kVA
Pumps  Bilge/GS/Fire
NAUTICAL AND COMMUNICATION EQUIPMENT
Search Lights  x2
Compass  x1
VHF  x1
GPS  x1
Echosounder  x1
Radar  x1
